    Large Table Rail Cable Durm Transfer Carts

    Ask Lasest Price
    Brand Name : BEFANBY
    Model Number : KPJ
    Certification : CE, SGS, ISO9001
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1500 set/sets per year
    Delivery Time : 20-30 days as usual delivery
    • Product Details
    • Company Profile

    Large Table Rail Cable Durm Transfer Carts

    Large Table Rail Cable Durm Transfer Carts

    Brief Introduction Of Transfer Carts

    The cable drum rail transporter is a heavy equipment that can be used in a variety of handling occasions. It is mainly used for cable collection, storage and transportation. Its core function is to ensure that the cable is wound or released in an orderly manner during movement, avoid entanglement and wear, and improve work efficiency and safety.

    Main application scenarios
    1. Port terminal: used for cable management of large cranes, gantry cranes and other equipment to ensure that the cables are synchronously retracted and released when the equipment moves.
    2. Mining: Maintain a stable supply of power cables when mining equipment (such as stackers and reclaimers, conveyors) moves.
    3. Metallurgical industry: used for cable management of heavy equipment such as continuous casting machines and rolling mills to prevent cables from dragging and wearing.

    Key advantages
    High degree of automation: can be used with motor, hydraulic or spring drive to achieve automatic cable retraction and release.
    Safe and reliable: prevent excessive stretching, twisting or breaking of cables, and reduce the risk of manual intervention.
    Strong adaptability: suitable for harsh environments (such as high temperature, humidity, dust, etc.).


    Large Table Rail Cable Durm Transfer CartsLarge Table Rail Cable Durm Transfer Carts

    Parts Of Rail Transfer Cart

    Large Table Rail Cable Durm Transfer Carts

    Advantage

    Flexible Operated Railway Mobile Reel Transport Trolley
    Flexible Operated Railway Mobile Reel Transport Trolley

    Technique Parameter Of Transfer Cart

    ModelKPT-2tKPT-5tKPT-10tKPT-16tKPT-20tKPT-25tKPT-30tKPT-40tKPT-50tKPT-63tKPT-80tKPT-100tKPT-150t
    Rated Load25101620253040506380100150
    Table sizeLength(L)20003500360040004000450045005000550056006000650010000
    Width(W)1500200020002000220022002200250025002500260028003000
    Height(H)4504505005005506006006506507508008501200
    Wheel Base1200250026002800280032003200380042004300470049007000
    Rail Inner Gauage1200143514351435143514351435143514351435180020002000
    Wheel Diameter270300300350350400400500500600600600600
    Wheel Quantity4444444444448
    Ground Clearance50505050505050505075757575
    Running Speed25252520202020202020202018
    Motor Power0.81.51.52.22.5345.55.57.57.51115
    Max Wheel Load14.425.842.664.577.794.5110.4142.8174221.4278.4343.8265.2
    Reference Weight2.33.33.855.566.37.27.610.312.113.926
    Recommended Rail ModelP15P18P18P24P24P38P38P43P43P50P50QU100QU100

    Application

    Flexible Operated Railway Mobile Reel Transport Trolley

    Shipping

    Flexible Operated Railway Mobile Reel Transport Trolley

    Brief Introduction

    Flexible Operated Railway Mobile Reel Transport Trolley

    Long Lifetime Railway Mobile Reel Transport Trolley
    Flexible Operated Railway Mobile Reel Transport Trolley
