Brand Name : | BEFANBY |
Model Number : | KPX |
Certification : | CE,SGS,ISO9001 |
Price : | Negotiation |
Payment Terms : | L/C, T/T |
Supply Ability : | 60 sets per month |
Delivery Time : | 40-50 days as usual delivery,30-40days for urgent delivery |
75 Ton Capacity Rail Electric Coils Trolley For Foundry Industry
Transport
75 Ton Capacity Rail Electric Coils Trolley For Foundry Industry Transport are designed based on customer requirements. Mostly there are special requirements regarding agility and manoeuvrability, carrying capacity, lift height, low overall height, etc.
For coils handling, BEFANBY engineer will free provide proper traveling solution after confirm the details:
1. Use frquency
2. How many coils transport once time?
3. Coils place direction
4. Load capacity
5. Coils diamater, size
6. Whether has other special requirement?
Advantages of 75 Ton Capacity Rail Electric Coils Trolley For Foundry Industry Transport
Model | KPX-2T | KPX-10T | KPX-20T | KPX-30T | KPX-50T | KPX-63T | KPX-150T | |
Rated load (T) | 2 | 10 | 20 | 30 | 50 | 63 | 150 | |
Table size | length(L) | 2000 | 3600 | 4000 | 4500 | 5500 | 5600 | 10000 |
Width(W) | 1500 | 2000 | 2200 | 2200 | 2500 | 2500 | 3000 | |
Height(H) | 450 | 500 | 550 | 600 | 650 | 700 | 1200 | |
Wheel Base (mm) | 1200 | 2600 | 2800 | 3200 | 4200 | 4300 | 7000 | |
Rail Inner Gauge (mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 2000 | |
Wheel Diameter(mm) | Φ270 | Φ300 | Φ350 | Φ400 | Φ500 | Φ600 | Φ600 | |
Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 75 | 75 | |
Running speed (min) | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | |
Motor Power (Kw) | 1 | 1.6 | 2.2 | 3.5 | 5 | 6.3 | 15 | |
Battery Capacity(Ah) | 180 | 160 | 180 | 250 | 330 | 400 | 600 | |
Battery Voltage(V) | 24 | 48 | 48 | 48 | 48 | 48 | 72 | |
Running Time When Full Load | 4.32 | 4.8 | 4 | 3.5 | 3.3 | 3 | 2.9 | |
Running Distance for one Charge(Km) | 6.5 | 7.2 | 4.8 | 4.2 | 4 | 3.6 | 3.2 | |
Max Wheel Load (KN) | 14.4 | 42.6 | 77.7 | 110.4 | 174 | 221.4 | 265.2 | |
Reference Weight (t) | 2.8 | 4.2 | 5.9 | 6.8 | 8 | 10.8 | 26.8 | |
Recommended Rail Model | P15 | P18 | P24 | P38 | P43 | P50 | QU100 |
Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a
professional and experienced manufacturer,exporter of material
transfer car in China, meanwhile we also design material handling
solution according to client's demand
![]() |
