    Hand Pendant Workshop Rail Transfer Cart Explosion Proof

    Ask Lasest Price
    Brand Name : BEFANBY
    Model Number : KPT
    Certification : CE SGS ISO9001
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 600 set/sets per year
    Delivery Time : 40-50 days as usual delivery,50-60days for urgent delivery
    • Product Details
    • Company Profile

    Hand Pendant Workshop Rail Transfer Cart Explosion Proof

    CE Workshop Custom Rail Traverser Ferry Rail Transfer Cart
    The rail traverser ferry transfer cart Composed By Upper Body And A Lower Bodys. The Lower Cart Is Laid On The Tracks For Ferries Or Transporting workpieces, And The Tracks And Lower Body Are Generally Designed Underground. The Upper Body Plane Is Flush With The Ground. The Lower Body Is Equipped With Rails For Docking, And The Different Rails Allow The Second Floor Body To Transport Items To Different Tracks Parallel To Each Other For Transitional Transport. It Is More Convenient And Can Be Used Alone Than A Rotating Platform, And Can Be Used In One Cars. The Shuttle Bus Can Be Designed In Three Layers According To Your Needs. Widely Used In Metallurgy, Machinery Manufacturing, Heavy Industry Manufacturing, Mold Manufacturing, Steel Plate Distribution, Building Materials Handling, Cement Plants, Steel Plants, Metal Processing Workshops And Other Industries.

    CE Workshop Custom Rail Traverser Ferry Rail Transfer CartCE Workshop Custom Rail Traverser Ferry Rail Transfer CartCE Workshop Custom Rail Traverser Ferry Rail Transfer Cart

    The cable powered rail traverser can be applied in the environment such as severe environment,explosion proof, high temperature, etc. Simple structure and low cost make the rail transfer cart popular for workshop transportation. The cable powered rail traverser can be applied in the different occasion with any loading capacity and high using frequency. If the running distance is beyond 50m, the cable powered transfer cars transportation needs to install cable arranger to help with cable rolling. The max running distance is up to 200-400m.

    CE Workshop Custom Rail Traverser Ferry Rail Transfer Cart


    Technique Parameter of KPT Series Customized Transfer Cart
    ModelKPT-2tKPT-5tKPT-10tKPT-16tKPT-20tKPT-25tKPT-30tKPT-40tKPT-50tKPT-63tKPT-80tKPT-100tKPT-150t
    Rated Load25101620253040506380100150
    Table sizeLength(L)20003500360040004000450045005000550056006000650010000
    Width(W)1500200020002000220022002200250025002500260028003000
    Height(H)4504505005005506006006506507508008501200
    Wheel Base1200250026002800280032003200380042004300470049007000
    Rail Inner Gauage1200143514351435143514351435143514351435180020002000
    Wheel Diameter270300300350350400400500500600600600600
    Wheel Quantity4444444444448
    Ground Clearance50505050505050505075757575
    Running Speed25252520202020202020202018
    Motor Power0.81.51.52.22.5345.55.57.57.51115
    Max Wheel Load14.425.842.664.577.794.5110.4142.8174221.4278.4343.8265.2
    Reference Weight2.33.33.855.566.37.27.610.312.113.926
    Recommended Rail ModelP15P18P18P24P24P38P38P43P43P50P50QU100QU100
    CE Workshop Custom Rail Traverser Ferry Rail Transfer Cart
    CE Workshop Custom Rail Traverser Ferry Rail Transfer Cart
    Our Customer

    CE Workshop Custom Rail Traverser Ferry Rail Transfer Cart
