    Hydraulic Steering Steel Platform Rail Track Trolley

    Ask Lasest Price
    Brand Name : BEFANBY
    Model Number : KPD
    Certification : CE,SGS,ISO9001
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 600 set/sets per year
    Delivery Time : 40-50 days as usual delivery,30-40days for urgent delivery
    • Product Details
    • Company Profile

    Hydraulic Steering Steel Platform Rail Track Trolley

    Steel Platform Motorized Electric Rail Track Trolley With Hydraulic Steering System

    Steel platform motorized electric rail track trolley with hydraulic steering system refers to an electric transfer car that can be raised and lowered on the steel platform. This series of electric rail track trolleys can lift and lower the table. The lifting system is generally a hydraulic lifting system, and the lifting system is stable. And does not affect the normal operation of the transfer trolley.


    Steel Platform Motorized Electric Rail Track Trolley With Hydraulic Steering SystemSteel Platform Motorized Electric Rail Track Trolley With Hydraulic Steering SystemSteel Platform Motorized Electric Rail Track Trolley With Hydraulic Steering System

    Feature

    • Anti-high temperature
    • Safe devices are installed
    • Customization can be supported
    • Apply to various occasions
    • The hydraulic lifting can be installed as per your true demand
    • V frame is added for cylinder
    • safety, flexibility, stable start, big starting torque, small capacity to the gear gearing
    • Running on the track, running smoothly.

    • The table can be raised and lowered.

    • The running speed is adjustable.


    Steel Platform Motorized Electric Rail Track Trolley With Hydraulic Steering System


    BEFANBY can customized different transfer cart from variour Industry

    Steel Platform Motorized Electric Rail Track Trolley With Hydraulic Steering System

    Technique Parameter
    ModelKPDZ-2tKPDZ-5tKPDZ-10tKPDZ-16tKPDZ-20tKPDZ-25tKPDZ-30tKPDZ-40tKPDZ-50tKPDZ-63t
    Rated load251016202530405063
    Table sizeLength(L)2000350036004000400045004500500055005600
    Width(W)1500200020002000220022002200250025002500
    Height(H)450450500500550600600650650750
    Wheel Base1200250026002800280032003200380042004300
    Rail Inner Gauage1200143514351435143514351435143514351435
    Wheel Diameter270300300350350400400500500600
    Wheel Quantity4444444444
    Ground Clearance50505050505050505075
    Running Speed0-250-250-250-200-200-200-200-200-200-20
    Motor Power11.21.622.233.5456.3
    Transformer Power3556.86.86.810101020
    Transformer Quatity1111111111
    Running Distance80808080808080605050
    Max Wheel Load14.425.842.664.577.794.5110.4142.8174221.4
    Reference Weight2.83.64.25.55.96.56.87.6810.8
    Recommended Rail ModelP15P18P18P24P24P38P38P43P43P50
    Brief Introduction----BEFANBY
    Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a collection of research, design, manufacture, installation and after-sales service of electric handling bogie ,transfer carts as one of the professional manufacturing company, which has a modernized management team and excellent staff.And our prodcuts gets CE, SASO,SGS,ISO certificate and other 8 national patent, our products have been exported to more than 40 countries and regions,such as Germany, Mexico, USA, Turkey, South Africa, Singapore etc.

    Steel Platform Motorized Electric Rail Track Trolley With Hydraulic Steering System


    Why Choose Us

    Steel Platform Motorized Electric Rail Track Trolley With Hydraulic Steering System

    Transportation Showing

    Steel Platform Motorized Electric Rail Track Trolley With Hydraulic Steering System


    How to choose suitable transfer trolley?
    All of our transfer carts all customized as client's requirement, for choose the most suitable transfer trolley,please kindly providing the following information:
    • Transfer or handling what material/cargo?
    • What capacity do you need?
    • This trasnfer trolley is running on rails or ground(floor)?
    • Your requirment for table size:length,width and height?
    • How about the running distance?
    • How many working hours in per day?
