    20m/Min Q235 Mould Flatbed Trailer Rail Transfer Cart

    Ask Lasest Price
    Brand Name : BEFANBY
    Model Number : KPX
    Certification : CE,SGS,ISO9001
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000 set/sets, per year
    Delivery Time : 40-50 days as usual delivery,30-40 days for urgent delivery
    • Product Details
    • Company Profile

    20m/Min Q235 Mould Flatbed Trailer Rail Transfer Cart

    Q235 Mould Flatbed Trailer Rail Transfer Cart With Wireless Remote Controller
    1. The Working Principle of Q235 Mould Flatbed Trailer Rail Transfer Cart With Wireless Remote Controller
    This q235 mould flatbed trailer rail transfer cart with wireless remote controller is usually used at ship yard, foundry industry, plant and factory, certain production line. The q235 mould flatbed trailer rail transfer cart with wireless remote controller could get power from outside or from the battery. The q235 mould flatbed trailer rail transfer cart with wireless remote controller was developed to dramatically reduce the material handling requirements of cranes and fork trucks while providing quick, safe and smooth movement of materials and/or products through manufacturing facilities. The q235 mould flatbed trailer rail transfer cart with wireless remote controller is based on our world renowned die power line trolleys and provides controlled movement of heavy and oversized loads such as dies, coils and work in progress. Our q235 mould flatbed trailer rail transfer cart with wireless remote controller is available in a number of configurations specifically designed to suit the needs of our customers. and the plc control system s optional as per the working demand.

    maintenance-free battery fork trucks gauge mm ship yard plc control system maintenance-free battery fork trucks gauge mm ship yard plc control system


    Q235 Mould Flatbed Trailer Rail Transfer Cart With Wireless Remote ControllerQ235 Mould Flatbed Trailer Rail Transfer Cart With Wireless Remote ControllerQ235 Mould Flatbed Trailer Rail Transfer Cart With Wireless Remote ControllerQ235 Mould Flatbed Trailer Rail Transfer Cart With Wireless Remote Controller


    2.The Charging Method of Q235 Mould Flatbed Trailer Rail Transfer Cart With Wireless Remote Controller

    maintenance-free battery fork trucks gauge mm ship yard plc control system

    The automatic charging of battery electric flatbed trailers is divided into offline charging and online charging.

    Offline charging is to charge the electric rail transfer cart when it is not working. The rail transfer cart can automatically run to the charging low point for charging, and the charging equipment can be automatically connected. Online charging is the opposite of offline charging. Online charging is automatic charging when the transfer cart is working. When the power of the transfer vehicle is less than 20% of the total amount during normal operation, the transfer vehicle will run to the charging place to charge itself. However, online automatic charging methods are limited to RGV and AGV methods, and manual control of flat cars is not available, so it is also called smart charging.

    maintenance-free battery fork trucks gauge mm ship yard plc control system

    Q235 Mould Flatbed Trailer Rail Transfer Cart With Wireless Remote Controller

    Q235 Mould Flatbed Trailer Rail Transfer Cart With Wireless Remote Controller


    Q235 Mould Flatbed Trailer Rail Transfer Cart With Wireless Remote Controller


    Q235 Mould Flatbed Trailer Rail Transfer Cart With Wireless Remote Controller
    3 Technical Parameter of Q235 Mould Flatbed Trailer Rail Transfer Cart With Wireless Remote Controller

    ModelKPX-2tKPX-20tKPX-50tKPX-100tKPX-150t
    Rated Load(t)22050100150
    Table Size(mm)Length(L)200040005500650010000
    Width(W)15002200250028003000
    Heigth(H)4505506509001200
    Wheel Base(mm)12002800420049007000
    Rail Inner Gauge(mm)12001435143520002000
    Wheel Diameter(mm)270350500600600
    Wheel Quantity44448
    Ground Clearance(mm)5050507575
    Running Speed(min)0-250-200-200-200-18
    Motor Power(kw)12.251015
    Battery Capacity180180330440600
    Battery Voltage2448487272
    Running time When Full Load4.3243.33.22.9
    Running Distance for Once Charge(KM)6.54.843.83.2
    Reference Weight(t)2.85.9814.626.8
    Recommended Rail ModelP15P24P43QU100QU100

    NOTES:

    • Flat deck or fixtures for transporting special payload;
    • Custom deck configurations may include lift, tilt, or rotate function;
    • Payload from 1 ton to 300 tons;
    • Fixed speed or variable speed capabilities;
    • On board charging is available if battery drives;
    • With forward or backing driving;
    • Options for automatic control;
    • Available safety equipment includes horn, lights, emergency stop, bumpers and detector. maintenance-free battery fork trucks gauge mm ship yard plc control system


    Q235 Mould Flatbed Trailer Rail Transfer Cart With Wireless Remote Controller

    maintenance-free battery fork trucks gauge mm ship yard plc control system

    5. BEFANBY Company
    maintenance-free battery fork trucks gauge mm ship yard plc control system

    Q235 Mould Flatbed Trailer Rail Transfer Cart With Wireless Remote Controller

    Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a collection of research, design, manufacture, installation and after-sales service of electric handling bogie ,transfer carts as one of the professional manufacturing company, which has a modernized management team and excellent staff.And 50 countries and regions,such as Germany, Mexico, USA, Turkey, South Africa, Singapore etc. maintenance-free battery fork trucks gauge mm ship yard plc control system

    Q235 Mould Flatbed Trailer Rail Transfer Cart With Wireless Remote Controller

    Q235 Mould Flatbed Trailer Rail Transfer Cart With Wireless Remote Controller
