    Railroad Workshop 40t Busbar Powered Transfer Cart

    Ask Lasest Price
    Brand Name : BEFANBY
    Model Number : KPC-25T
    Certification : CE,SGS,ISO9001
    Price : Negotiation
    Payment Terms : 30% deposit by T/T in advance, 70%balance by T/T before dispatch
    Supply Ability : 600 sets one year
    Delivery Time : 40-50 days as usual delivery,30-40days for urgent delivery
    • Product Details
    • Company Profile

    Railroad Workshop 40t Busbar Powered Transfer Cart

    power distribution transformer three phase power transformer electrical power transformer 10 mva power transformer electric control system
    Customized Workshop Railroad Transfer Traverses For Rail Car Facility 40 T
    Working principle of sliding line powered rail transfer traverser

    The rail traverser is power by busbar(electric sliding line). It gets power from sliding during the cart running. The electric control system of the cart realize it start, stop, go forward and backward.

    power distribution transformer three phase power transformer electrical power transformer 10 mva power transformer electric control system

    The Position Of Sliding Wire

    The position of the rail car sliding line is adapted to local conditions and determined according to the specific conditions of each user. It can be installed in the middle of the track, on one side of the track, in a trench, or on a wall, or under the flatbed, or above the flatbed, or it can be flush with the flatbed. Based on the principle of convenient, safe and reliable electricity, for example, install the sliding contact line in the trench, install the cover plate on the trench (the cover plate is not a through plate, but one by one), and install a cover plate on the flatbed truck. The board mechanism, when the car is walking, the board is opened and automatically closed, which is safe and beautiful.
    power distribution transformer three phase power transformer electrical power transformer 10 mva power transformer electric control system
    Customized Workshop Railroad Transfer Traverses For Rail Car Facility 40 TCustomized Workshop Railroad Transfer Traverses For Rail Car Facility 40 TCustomized Workshop Railroad Transfer Traverses For Rail Car Facility 40 TCustomized Workshop Railroad Transfer Traverses For Rail Car Facility 40 T

    Detailed description of the rail traverser

    This kind of large gauge rail traverser is running on steel tracks or steel squre bars. For special handling requirement, additional rails can be installed on the platform of the rail traverser, then another rail cart can run on the platform. It can solve the transferring problem with crossing rail or 90 degree rails.


    Technical parameters of rail traverser

    Model
    KPC-2TKPC-10TKPC-20TKPC-30TKPC-50TKPC-63TKPC-150T
    Rated load (T)21020305063150
    Table sizelength(L)20003600400045005500560010000
    Width(W)1500200022002200250025003000
    Height(H)4505005506006507001200
    Wheel Base (mm)1200260028003200420043007000
    Rail Inner Gauge (mm)1200143514351435143514352000
    Wheel Diameter(mm)Φ270Φ300Φ350Φ400Φ500Φ600Φ600
    Wheel Quantity4444448
    Ground Clearance (mm)50505050507575
    Running speed (min)0-250-250-200-200-200-200-18
    Motor Power (Kw)11.62.23.556.315
    Battery Capacity(Ah)180160180250330400600
    Battery Voltage(V)24484848484872
    Running Time When Full Load4.324.843.53.332.9
    Running Distance for one Charge(Km)6.57.24.84.243.63.2
    Max Wheel Load (KN)14.442.677.7110.4174221.4265.2
    Reference Weight (t)2.84.25.96.8810.826.8
    Recommended Rail ModelP15P18P24P38P43P50QU100
    Application of crossing rail traverser

    This kind of large gauge rail traverser is running on steel tracks or steel squre bars.It is commonly applied in steel plant, aluminum factory, plastic pipes factory, etc to transfer rounded material, from producing line to store.

    It is the best choice for production line with large rail gauge.


    rail traverserCustomized Workshop Railroad Transfer Traverses For Rail Car Facility 40 T


    Customized Workshop Railroad Transfer Traverses For Rail Car Facility 40 TCustomized Workshop Railroad Transfer Traverses For Rail Car Facility 40 T


    This kinf of rail traverser has wide rail gauge.When the traverser is applied to transfer coils, a V-frame is added.


    Customized Workshop Railroad Transfer Traverses For Rail Car Facility 40 T Customized Workshop Railroad Transfer Traverses For Rail Car Facility 40 T

    The rail traverser is applying in customer's workshop to transfer steel coils on crossing rails. The large platform can handling the rail cart to the crossing rails freely.
    power distribution transformer three phase power transformer electrical power transformer 10 mva power transformer electric control system

    Other type rail transfer car BEFANY Can Supply
    power distribution transformer three phase power transformer electrical power transformer 10 mva power transformer electric control system

    Customized Workshop Railroad Transfer Traverses For Rail Car Facility 40 TCustomized Workshop Railroad Transfer Traverses For Rail Car Facility 40 T

    Customer visit in our factory

    Customized Workshop Railroad Transfer Traverses For Rail Car Facility 40 T




    Our company

    Customized Workshop Railroad Transfer Traverses For Rail Car Facility 40 T


    FAQ

    1. Q: What is the capacity of the rail traverser? A: The capacity can be customized, the max. Load capacity can reach to 300 tons.

    2. Q: What is the using candition?
    A: The environment temperature should be in level. such as production line

    3. Q: What is the working speed of the ladle car?
    A: The standard running speed is 0-20m/min.
