Intelligent Q235 25m/Min 12t Agv Die Transport Cart

Ask Lasest Price
Brand Name :	BEFANBY
Model Number :	mold
Certification :	CE, SGS, ISO9001
Price :	Negotiation
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	800 sets per year
Delivery Time :	20-30 working days for usual delivery

Add to Cart

Product Details
Company Profile

Intelligent Q235 25m/Min 12t Agv Die Transport Cart

12 ton Intelligent Agv Die Transport Cart For Light Industrial

The 12ton intelligent agv die transport cart for light industrial (AGV), also commonly known as the AGV car, is equipped with automatic guiding devices such as electromagnetic or optical, inertial navigation, etc., which can travel along a prescribed guiding path and has safety protection. the intelligent agv die transport cart with various transfer functions, no need for the driver's van in industrial applications, and a rechargeable battery as the power source.

2019 China steerable battery powered material handling trackless electric transfer cart

With the expansion of the application field, the types and forms of AGVs become diverse. AGVs are often classified into the following types according to the navigation method during AGV automatic driving:

Compared with electromagnetic guidance, magnetic navigation uses magnetic strips on the road surface instead of embedding metal wires under the ground to realize navigation through magnetic induction signals. Flexibility is better, it is easier to change or expand the path, and the magnetic strip is easy to lay. The navigation method is mechanically damaged by hard objects such as metal passing through the loop, which has a certain influence on navigation.

The features as following:

The agv transfer cart is battery powered, they represent the best solution for all those appliances with delicate handling problems in limited places.(360 degree turning flexibly)
The agv trackless transfer cart is very flexible since it can move freely around the plant as indoor as outdoor.
It is equipped with non-marking wheels to avoid any mark on floor.(Imported PU wheel or customized)
Easy operation make transfer cart perfect to meet the most important requirements: where space is very limited and paths are strictly constrained.

Remark: Dimensions,capacity, loading platform superstructure, speed and many others features can be customized as per client request.

12 ton Intelligent Agv Die Transport Cart For Light Industrial

Technical Parameter of 2 ton Intelligent Agv Die Transport Cart For Light Industrial

Model		BWP-10t	BWP-20t	BWP-40t	BWP-60t	BWP-80t	BWP-100T
Rated Load(t)		10	20	40	60	80	100
Table size(mm)	Length(L)	2300	2400	5000	5600	6500	6600
	Width(W)	2000	2200	2500	2500	2800	3300
	Height(H)	550	600	800	850	950	1200
Wheel Base(mm)		1650	1650	2000	1800	1950	2000
Axle Base(mm)		1700	1850	3600	2900	3500	4000
Wheel Diameter(mm)		350	400	500	600	600	600
Wheel Quantity(pcs)		4	4	4	4	6	8
Ground Clearance(mm)		50	50	50	75	75	75
Running Speed(m/min)		0-25	0-20	0-20	0-20	0-20	0-18
Motor Power(kw)		2*2.2	2*3.5	2*6.3	2*10	30	40
Battery Capacity(Ah)		250	330	440	600	800	1000
Battery Voltage(v)		48	48	72	72	72	72
Max Wheel Load(kn)		42.6	77.7	142.8	221.4	185	190
Reference Weight		4.2	5.9	7.6	10.8	14.6	26.8

12 ton Intelligent Agv Die Transport Cart For Light Industrial

Brief introduction----BEFANBY'S Advantage

Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a collection of research, design, manufacture, installation and after-sales service of electric handling bogie ,transfer carts as one of the professional manufacturing company, which has a modernized management team and excellent staff.And our prodcuts gets CE, SASO,SGS,ISO certificate and other 8 national patent, our products have been exported to more than 40 countries and regions,such as Germany, Mexico, USA, Turkey, South Africa, Singapore etc.

Brief introduction----BEFANBY'S Certificate

12 ton Intelligent Agv Die Transport Cart For Light Industrial

Tag: Steerable Transfer Car, Motorized Transport Car
