kpd-60 tons electric transfer trolley, motorized transfer trolley
manufacturers for working line
1. Product Introduce
BEFANBY kpd-60 tons electric transfer trolley, motorized transfer
trolley manufacturers for working line is powered by low voltage electricity from railways, the kind of
transfer trolley is one of the most convenient material handling
equipment and it often can be widely used in the industry field an
so on. Of course,compared other transfer trolley,it main features
as it follows,its rails is isulated with the ground, and its wheels
are isulated with the ground, so doesn't others.it is the advantage
that the tracks trolley have, why we design is that its convenient
(only rails needed) and its simple operation.
About BEFANBY, Our company have professional team and utilize more
advanced technique to design and develope it , and it has been a
long year to manufacture it attentively. Simutaneously, it will be
more easy and flexible.Simple structure and low cost make it
popular for workshop transportation.
Please contact us if you's like to learn more details and get the
quotation.
BEFANBY have over 16 years' experience in the material handling
fields. |
2. Working Principle of kpd-60 tons electric transfer trolley, motorized transfer trolley
manufacturers for working line
BEFANBY KPD-60 tons electric transfer trolley, motorized transfer
trolley manufacturers for working line, the power source AC380v is
transformed into AC36v two-phase and are respectively connected to
the two rails.Then the flat carts' wheels conduct the AC36v on rail
into the electrical appliance box at the bottom of the carts, And
then the AC36v is transformed into DC36v and then control the DC
motor through the DC control system to make the flat carts start,
stop, go forward and backward railways.
3. Feature of kpd-60 tons electric transfer trolley, motorized transfer trolley
manufacturers for working line
1. Anti-high temperature
2. Safe devices are installed(alarm light, dead man stop, e-stop,
lamp, bumper, etc)
3. Customization can be supported
4. If required large load capacity, dual drive can be installed,
and the largest capacity can reach to 500T
5. China manufacturing
6. Apply to various occasions
7. safety, flexibility, stable start, big starting torque, small
capacity to the gear gearing
8. Low voltage, long lifetime
9. The running distance is not limited.
10. When the running distance is more than 70m, it is better to
increase the transformers to make up for the voltage which as been
lowed.
11. The transfer trolley can be used in turning occasions, suach as
"S“ "C" arc-shaped rail, etc.
4. Technique Parameter of kpd electric transfer trolley, motorized transfer trolley
manufacturers for working line
| Model | KPD-2t | KPD-5t | KPD-10t | KPD-16t | KPD-20t | KPD-25t | KPD-30t | KPD-40t | KPD-50t | KPD-63t |
| Rated load | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 |
| Table size | Length(L) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 |
| Width(W) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2500 |
| Height(H) | 450 | 450 | 500 | 500 | 550 | 600 | 600 | 650 | 650 | 750 |
| Wheel Base | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 |
| Rail Inner Gauage | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 |
| Wheel Diameter | 270 | 300 | 300 | 350 | 350 | 400 | 400 | 500 | 500 | 600 |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
| Ground Clearance | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 |
| Running Speed | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 |
| Motor Power | 1 | 1.2 | 1.6 | 2 | 2.2 | 3 | 3.5 | 4 | 5 | 6.3 |
| Transformer Power | 3 | 5 | 5 | 6.8 | 6.8 | 6.8 | 10 | 10 | 10 | 20 |
| Transformer Quatity | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Running Distance | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 60 | 50 | 50 |
| Max Wheel Load | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 |
| Reference Weight | 2.8 | 3.6 | 4.2 | 5.5 | 5.9 | 6.5 | 6.8 | 7.6 | 8 | 10.8 |
| Recommended Rail Model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 |
6.Brief Introduction----BEFANBY
Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a
collection of research, design, manufacture, installation and
after-sales service of electric handling bogie ,transfer carts as
one of the professional manufacturing company, which has a
modernized management team and excellent staff.And our prodcuts
gets CE, SASO,SGS,ISO certificate and other 8 national patent, our
products have been exported to more than 60 countries and
regions,such as Saudi Arabia, UAE, Malaysia, Singapore, Singapore,
Australia, Canada, Mexico, Germany, etc.
BEFANBY CERTIFICATION
7. How to choose suitable transfer trolley?
All of our transfer trolleys can be customized as client's
requirement, for choose the most suitable and economic transfer
trolley,please kindly providing the following information:- Transfer or handling what material/cargo?
- What capacity do you need?
- This trasnfer trolley is running on rails or ground(floor)?
- Your requirment for table size:length,width and height?
- How about the running distance?
- How many working hours in per day?
