    50 Tons Ladle Transfer Cart Steel Mill Material Electric Scale Custom Length

    Ask Lasest Price
    Brand Name : BEFANBY
    Model Number : KPX-25T
    Certification : CE,SGS,ISO9001
    Price : Negotiation
    Payment Terms : 30% deposit by T/T in advance, 70%balance by T/T before dispatch
    Supply Ability : 600 sets one year
    Delivery Time : 50-60 days as usual delivery,40-50days for urgent delivery
    • Product Details
    • Company Profile

    50 Tons Ladle Transfer Cart Steel Mill Material Electric Scale Custom Length

    50 tons high tempetature apply steel mill ladle transfer car with electric scale
    Working principle of steel mill ladle transfer car

    The mill ladle transfer car is powered by battery. The battery supply power to the DC motor, which is installed inside of cart body. Through the order of start, stop, forward, back, speed governing, etc, electrical control system command the order to DC motor to drive rail ladle car working.


    50 Tons Ladle Transfer Cart Steel Mill Material Electric Scale Custom Lengthsteel metal scrap carts


    Features of steel mill ladle transfer car
    • Box girder structure;
    • Anti-high temperature and explosion-proof;
    • PLC automatic control;
    • Can be add hydraulic lifting device;
    • Can be add dumping device;
    • Electric weighing scale and LED display can be installed;
    • Can run on straight rails or arc-rail, turning rails;
    • Low failure rate, working steady;
    • High efficiency, low energy consumption;
    • Reasonable design, reliable operation;
    Application of steel mill ladle transfer car

    The steel mill ladle transfer car is commonly applied in steel industry or metallurgy industry to transfer liquid steel, steel ladle, steel scraps, etc. It can be used within workshop handling or between workshops.


    In order to ensure the platform and driving system damaged by high-temperature, there is firebrick laid on the platform of the ladle. Or the driving system is protected by special design. This kind of ladle car can run on both straight rails and S-shaped rails.


    steel mill ladle transfer car


    steel mill ladle transfer car


    The applying site in one of our client’s factory, they use the scrap bucket carts to transfer steel scraps ladle from production line to warehouse. In order to improve the working efficiency, the use two sets ladle cars for alternative using.


    Several kinds of of steel mill ladle transfer car


    steel mill ladle transfer carsteel mill ladle transfer carsteel mill ladle transfer carsteel mill ladle transfer car


    Technical parameters of steel mill ladle transfer car
    Model
    KPX-2TKPX-10TKPX-20TKPX-30TKPX-50TKPX-63TKPX-150T
    Rated load (T)21020305063150
    Table sizelength(L)20003600400045005500560010000
    Width(W)1500200022002200250025003000
    Height(H)4505005506006507001200
    Wheel Base (mm)1200260028003200420043007000
    Rail Inner Gauge (mm)1200143514351435143514352000
    Wheel Diameter(mm)Φ270Φ300Φ350Φ400Φ500Φ600Φ600
    Wheel Quantity4444448
    Ground Clearance (mm)50505050507575
    Running speed (min)0-250-250-200-200-200-200-18
    Motor Power (Kw)11.62.23.556.315
    Battery Capacity(Ah)180160180250330400600
    Battery Voltage(V)24484848484872
    Running Time When Full Load4.324.843.53.332.9
    Running Distance for one Charge(Km)6.57.24.84.243.63.2
    Max Wheel Load (KN)14.442.677.7110.4174221.4265.2
    Reference Weight (t)2.84.25.96.8810.826.8
    Recommended Rail ModelP15P18P24P38P43P50QU100
    Delivery of steel mill ladle transfer car

    steel mill ladle transfer car

    Customer visit in our factory

    steel metal scrap bucket carts steel metal scrap bucket carts


    Customer feedback


    steel mill ladle transfer car

    Quality control of steel mill ladle transfer car

    steel mill ladle transfer car


    Other steel mill ladle transfer car in BEFANBY company

    steel metal scrap bucket carts steel metal scrap bucket carts 50 Tons Ladle Transfer Cart Steel Mill Material Electric Scale Custom Length steel metal scrap bucket carts

    steel mill ladle transfer car


    Our service


    • Our commitment: The load bearing safety factor of the trolley is no less than 120%.
    • Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.
    • 16 hours engineering service and 24 hours internet service for our customers.
    • During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours
    • Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
