    25t Electric power DC motor heavy material foundry plant rail car

    Ask Lasest Price
    Brand Name : BEFANBY
    Model Number : KPDZ-25T
    Certification : CE,SGS,ISO9001
    Price : Negotiation
    Payment Terms : 30% deposit by T/T in advance, 70%balance by T/T before dispatch
    Supply Ability : 600 sets one year
    Delivery Time : 50-60 days as usual delivery,40-50days for urgent delivery
    • Product Details
    • Company Profile

    25t Electric power DC motor heavy material foundry plant rail car

    25T Electric power DC motor heavy material foundry plant rail car

    Description of 25t rail car


    The frame of rail car is welded by high quality steel, with the assistant of running mechanism , gears, AC motor, current collector, the cart will function under the control system. The transfer cart is remote control, or PLC control.


    25t Electric power DC motor heavy material foundry plant rail car 25t Electric power DC motor heavy material foundry plant rail car


    The rail car is composed of motor, reducer, electric appliance and wheels. Due to more parts, compared with other carts, it has large size. But it can’t influence its working property.


    Frame Driving system Steel wheel

    rail car

    Reducer Light & sound alarm Bumper


    Functions of rail car

    • Go forward and backward,
    • Turn left and right,
    • Adjust speed button,
    • Indicator light,
    • Electric indicator light and other control buttons.
    Working principle of rail car

    KPD type rail car is powered from 36v two-phase rails. It is two-phase electricity on rails. the transfer cart’s wheels conduct the AC 36v on rail into the electrical appliance box at the bottom of the carts. And then the AC 36v is transfer into DC 36v and then control the DC motor through the DC control system to make transfer cart start,stop,forward, and backward,etc.


    The voltage of operating system is 36v safe voltage. After the transformer step-down from 380v AC three-phase, the rails got the electricity.


    Advantages of rail car

    • Has no lit on using time and high working frequency;
    • Can be used in high-temperature environment;
    • Can be used in explosion-proof environment;
    • Safety and flexibility;
    • Large toad capacity, can reach to 50 tons;

    Detailed description of the rail car


    The rail car is suitable for working environment with not so long running distance, such as steel factory, machinery manufacturing plant, etc.


    25t Electric power DC motor heavy material foundry plant rail car 25t Electric power DC motor heavy material foundry plant rail car


    25t Electric power DC motor heavy material foundry plant rail car 25t Electric power DC motor heavy material foundry plant rail car


    The rail transporter is applied in motor production line to transfer heavy motor parts bay to bay.

    25t Electric power DC motor heavy material foundry plant rail car 25t Electric power DC motor heavy material foundry plant rail car


    Technical parameters of rail transporter

    ModelKPDZ-2tKPDZ-20tKPDZ-50tKPDZ-100tKPDZ-150t
    Rated Load(t)22050100150
    Table Size(mm)Length(L)200040005500650010000
    Width(W)15002200250028003000
    Heigth(H)4505506508501200
    Wheel Base(mm)12002800420049007000
    Rail Inner Gauge(mm)12001435143520002000
    Wheel Diameter(mm)270350500600600
    Wheel Quantity44448
    Ground Clearance(mm)5050507575
    Running Speed(min)0-250-200-200-200-18
    Motor Power(kw)0.82.55.51115
    Transformer Power(KVA)36.8103030
    Transformer Quanity11111
    Running Distance(m)7070505050
    Max Wheel Load(KN)14.477.7174343.8265.2
    Reference Weight(t)2.85.9814.626.8
    Recommended Rail ModelP15P24P43QU100QU100


    Delivery of transfer platform

    Generally the rail transporter is delivery through container, but if the platform is too large, it can be delivery through frame rack
    Customer visit in our factory

    ladle car ladle car

    Quality control of rail transporter

    rail car

    Other product of BEFANBY company


    Our company

    rail car

    Our certificate


    FAQ

    1. Q: What is the capacity of the rail car? A: The capacity can be customized, the max. Load capacity can reach to 300 tons.

    2. Q: What is the using candition?
    A: The environment temperature should be in level. such as production line

    3. Q: What is the working speed of the car?
    A: The standard running speed is 0-20m/min.
