Heavy duty material handling motorized 10 ton battery powered
electric rail transfer cart
BEFANBY designed and manufactured the battery powered rail transfer
cart and provide innovative handling solution with more than 16
years'experience.the rail cart can be used in industry plant, port,
workshop, production line and so on to transport ladle, coil, mold,
steel products, workpiece and so on.All the solution are designed
as per customers true demand.
The battery powered rail transfer cart is a good choice if meeting
the following features:
1.The running distance is not limited for the battery powered rail
transfer cart
2.Low using frequency(The spare battery can be provided if higher
using frequency)
3.Despite of turning or going straight, the rail transfer cart can
realize
4.Despite of running on indoor or outdoor, high temperarture or
explosive environment, ferry or cross rail, the transfer cart can
realize. Heavy duty transfer electric battery power railroad carts
5.Dimensions,capacity, loading platform superstructure, speed and
many others special funcition can be customized as per client
request Heavy
Character Showing of Heavy duty material handling motorized 10 ton battery powered
electric rail transfer cart
1. High level automation(self propelled/steerable)
2. The largest capacity can reach to 500 ton
3. Safe parts are installed in the railroad cart(warning light,
e-stop, buffer...)
4. Robust sturdy car frame
5. AC/DC electric engine , diesel engine or pneumatic engine
6. Excellent gear reducer and motor with high quality, assemblied
together perfectly
7. Remote control&hand pendant control make the opration more
convenient.
8. The speed can be adjusted
9. Easy operation and maintenance
10. Famous brand parts, guarantee the quality and prolong the using
lifetime
11. Low noise and do not pollute the environment
Working Principle of electric material handling Motorized Transfer
Cart china factory
The kinds of motorized transfer cart is battery powered . The
battery is installed in the carts. The batteries supplied the
electricity to the DC motor through the electrical control system.
By this ways, we can make the flat cart to start, stop, go forward
, back ward , adjust the speed and so on.
Technique Parameter of heavy duty material handling electric Motorized Transfer Cart
| Model | KPX-2t | KPX-5t | KPX-10t | KPX-16t | KPX-20t | KPX-25t | KPX-30t | KPX-40t | KPX-50t | KPX-63t | KPX-80t | KPX-100t | KPX-150t |
| Rated Load | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 |
| Table size | Length(L) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| Width(W) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 |
| Height(H) | 450 | 500 | 500 | 550 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 |
| Wheel Base | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 |
| Rail Inner Gauage | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 |
| Wheel Diameter | 270 | 300 | 300 | 350 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 |
| Ground Clearance | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 |
| Running Speed | 25 | 25 | 25 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 18 |
| Motor Power | 1 | 1.2 | 2 | 2.2 | 3 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | 15 |
| Battery Capacity | 180 | 180 | 160 | 180 | 180 | 250 | 250 | 300 | 330 | 400 | 400 | 440 | 600 |
| Battery Voltage | 24 | 36 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 |
| Running Time When Full Load | 4.32 | 5.4 | 4.8 | 4.3 | 4 | 4 | 3.5 | 3.6 | 3.3 | 3 | 3.6 | 3.2 | 2.9 |
| Max Wheel Load | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 |
| Reference Weight | 2.8 | 3.6 | 4.2 | 5.5 | 5.9 | 6.5 | 6.8 | 7.6 | 8 | 10.8 | 12.8 | 14.6 | 26.8 |
| Recommended Rail Model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 | QU100 |
Processing of electric battery operated motorized transfer cart China factory
Packing& Delivery of electric Industrial Usage Motorized Transfer Cart china factory
Our Company----BEFANBY
Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a collection of research, design, manufacture, installation and
after-sales service of electric handling bogie ,transfer carts as
one of the professional manufacturing company, which has a
modernized management team and excellent staff.And our prodcuts
gets CE, SASO,SGS,ISO certificate and other 8 national patent, our
products have been exported to more than 40 countries and
regions,such as Germany, Mexico, USA, Turkey, South Africa,
Singapore etc.
You can copy the following options and click here to select your
specific requirement for the transfer cart to send us. And then the
proper solution and price will be sent to you.
1. The load capacity of the transfer cart is ( ) ton.
2. The table size is ( ) mm (L) * ( ) mm (W)*( ) mm (H).
3. The voltage is ( ) V, ( ) HZ, 3 phase.
4. The running time is ( ) hours per day.
5. The running distance is ( ) m per time.
6. The transfer cart runs on the rails or common floor?
7. Whether exist turning?
8. Whether has other special requirement?
