    Long Distance Forklift Battery Transfer Cart Variable Speed Q235 Material

    Ask Lasest Price
    Brand Name : BEFANBY
    Model Number : KPX
    Certification : CE,SGS,ISO9001
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 800 set/sets, per year
    Delivery Time : 40-50 days as usual delivery,30-40days for urgent delivery
    • Product Details
    • Company Profile

    Long Distance Forklift Battery Transfer Cart Variable Speed Q235 Material

    Long Distance Forklift Battery Transfer Cart Variable Speed Q235 Material
    1. Product description

    BEFANBY's Long Distance Forklift Battery Transfer Cart Variable Speed Q235 Material are movable vehicle used for the horizontal movement of materials, assemblies and other items. It is powered by storage battery, which is installed on the transfer carts. The transfer carts are manual guide vehicles equipped with specialized drive systems which make it possible to easily, precisely and safely move up to 500 tons. Generally the heavy loads transfer carts are used to accommodate the needs of a wide range of industries including Steel, Aluminum, Automotive, Heavy Manufacturing and others.These carts are designed to operate on floor mounted rails and are used to transport heavy materials across crane bays or in areas not serviced by an overhead crane.

    drive systems flat trailers lifting platforms manual guide 4 corners drive systems flat trailers lifting platforms manual guide 4 corners

    Long Distance Forklift Battery Transfer Cart Variable Speed Q235 Material

    Long Distance Forklift Battery Transfer Cart Variable Speed Q235 Material


    2. Application Showing of Long Distance Forklift Battery Transfer Cart Variable Speed Q235 Material

    BEFANBY conceives and manufactures a wide range of railway guided transfer carts, battery powered transfer carts, intelligent self-propelled trolleys, die carts, industrial flat trailers, tilters and lifting platforms that operate in many industrial fields: metallurgy, manufacture, oil and gas, die shops, shipyards, chemical plant, automotive, mining industry, aerospace, power generation, coal industry, paper mills, metalworking, warehouse and many others!

    drive systems flat trailers lifting platforms manual guide 4 corners

    Long Distance Forklift Battery Transfer Cart Variable Speed Q235 Material

    3. Operation of Long Distance Forklift Battery Transfer Cart Variable Speed Q235 Material
    drive systems flat trailers lifting platforms manual guide 4 corners drive systems flat trailers lifting platforms manual guide 4 corners
    There are a variety of drive and control systems for the battery transfer carts. Drive systems include gear reducer, axle drives and individual wheel drives. A typical unit is equipped with a hand held pendant control which is used by the operator to control the transfer car to move backward, forward along the track. With an average travel speed of 20m/min, an operator can walk along with the car to operate the unit. The pendant can be provided to be mounted on any of the 4 corners of the vehicle to allow the operator to walk along the leading end of the vehicle during operation. And our transfer cars are also available with semi-automatic and fully automatic control systems to meet the needs of specialized applications.
    Long Distance Forklift Battery Transfer Cart Variable Speed Q235 Material
    4. Technique Parameter of Long Distance Forklift Battery Transfer Cart Variable Speed Q235 Material
    drive systems flat trailers lifting platforms manual guide 4 corners
    ModelKPX-2tKPX-5tKPX-10tKPX-16tKPX-20tKPX-25tKPX-30tKPX-40tKPX-50tKPX-63tKPX-80tKPX-100tKPX-150t
    Rated Load25101620253040506380100150
    Table sizeLength(L)20003500360040004000450045005000550056006000650010000
    Width(W)1500200020002000220022002200250025002500260028003000
    Height(H)4505005005505506006006506507008009001200
    Wheel Base1200250026002800280032003200380042004300470049007000
    Rail Inner Gauage1200143514351435143514351435143514351435180020002000
    Wheel Diameter270300300350350400400500500600600600600
    Wheel Quantity4444444444448
    Ground Clearance50505050505050505075757575
    Running Speed25252520202020202020202018
    Motor Power11.222.233.5456.38101515
    Battery Capacity180180160180180250250300330400400440600
    Battery Voltage24364848484848484848727272
    Max Wheel Load14.425.842.664.577.794.5110.4142.8174221.4278.4343.8265.2
    Reference Weight2.83.64.25.55.96.56.87.6810.812.814.626.8
    5. What Product Handling Applications Use Transfer Carts?
    1. Coils (V-Groove deck)
    2. Tanks (size/stability for uniformly distributed loads)
    3. Assemblies (fixture cradle) for a complete build or to send a partially completed product to the next station (tractors, heavy equipment machinery)
    4. Sub-Assembly shuttle from one line to another line
    5. Maintenance cart for motors and pumps
    6. Equipment support (stand-off deck) for navigating loads to locations with a plant facility
    7. Material shuttle for steel tubing (flat decking with guard rails)
    8. Elevating platform for assembly process (integrated screw-jack table)
    9. Sand casting (flat decking)
    6. Contact us

    Free provide economic handling solutions to you once received your inquiry.


    If you'd like to learn more, also can click: www.chinatransfercart.com


    or www.bfbhandling.com


    Or

    Contact: Maria Ji


    Email: Sale01@bfbhandling .com


    Tel:+86-15560181018


    Xinxiang Hundred Percent Electrical And Mechanical Co., Ltd


    Xinxiang Hundred Percent Electrical And Mechanical Co., Ltd is a professional manufacturer and exporter of material handling equipment since 2003. we can supply different powered transfer cart, such an battery powered, conductor rail powered, cable drum powered, dragged cable powered, busbar powered, no powered and so on. the transfer cart can run on rails or common cement floor.
