    Remote Control 5t Side Dump Rail Transfer Trolley 20m/Min

    Ask Lasest Price
    Brand Name : BEFANBY
    Model Number : KPX-50 ton
    Certification : CE,SGS,ISO9001
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 100 sets per month
    Delivery Time : 40-50 days as usual delivery,30-40days for urgent delivery
    • Product Details
    • Company Profile

    Remote Control 5t Side Dump Rail Transfer Trolley 20m/Min

    5t Electric Side-Dump Transfer Trolley On Rails


    The befanby side-dump transfer trolley powered by battery, gets rid of the restraint of the cable. it can dump goods from one side by lifting the other side to a certain angle through the hydraulic device. through the side-dumping function, the automatic unloading of the goods is realized, satisfying customer`s automatic unloading. we can customize the lift cart of different heights according to your different requirement. so that you can use them at different heights. the lift height of the counters can also be adjusted according to your needs and usage.


    ModelKPX-2TKPX-10TKPX-20TKPX-30TKPX-50TKPX-63TKPX-150T
    Rated load (T)21020305063150
    Table sizelength(L)20003600400045005500560010000
    Width(W)1500200022002200250025003000
    Height(H)4505005506006507001200
    Wheel Base (mm)1200260028003200420043007000
    Rail Inner Gauge (mm)1200143514351435143514352000
    Wheel Diameter(mm)Φ270Φ300Φ350Φ400Φ500Φ600Φ600
    Wheel Quantity4444448
    Ground Clearance (mm)50505050507575
    Running speed (min)0-250-250-200-200-200-200-18
    Motor Power (Kw)11.62.23.556.315
    Battery Capacity(Ah)180160180250330400600
    Battery Voltage(V)24484848484872
    Running Time When Full Load4.324.843.53.332.9
    Running Distance for one Charge(Km)6.57.24.84.243.63.2
    Max Wheel Load (KN)14.442.677.7110.4174221.4265.2
    Reference Weight (t)2.84.25.96.8810.826.8
    Recommended Rail ModelP15P18P24P38P43P50QU100

    Application

    The side-dump transfer trolley is mainly applied in production line (raw material handling, finished products transportation), steel factory (steel bar, steel billet, steel plate, steel coil, steel pipe, section steel, steel structure), warehouse transport, mold plant (dies, molds transport from one bay to another), metallurgy industry (steel ladle, scrap ladle), ship industry (steel parts transfer, maintenance, assemble, container transport), workpieces transport in workshop, lathe transport, construction (bridge, simple building, concrete, concrete column), energy (poly crystalline silicon, generator, windmill), chemical industry (electrolytic cell, retort, equipment transport), etc.


    5t Electric Side-Dump Transfer Trolley On Rails5t Electric Side-Dump Transfer Trolley On Rails

    5t Electric Side-Dump Transfer Trolley On Rails

    5t Electric Side-Dump Transfer Trolley On Rails

    5t Electric Side-Dump Transfer Trolley On Rails

    5t Electric Side-Dump Transfer Trolley On Rails






    5t Electric Side-Dump Transfer Trolley On Rails

    BEFANBY Company
    5t Electric Side-Dump Transfer Trolley On Rails


    Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a professional and experienced manufacturer,exporter of material transfer car in China, meanwhile we also design material handling solution according to client's demand

    Cutomer from worldwide


    5t Electric Side-Dump Transfer Trolley On Rails


    BEFANBY advantages
    • Our commitment: The load bearing safety factor of the trolley is no less than 120%.
    • Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.
    • 16 hours engineering service and 24 hours internet service for our customers.
    • During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.
    • Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
